The float section of the TRIDENT-3000 is built from four (4) rotationally-moulded quadrants, which fasten together to form an incredibly robust 3 meter wide float section standing 1.8 meters tall. Each quadrant is moulded from UV-stabilised, virgin polyethylene, and has an 18mm wall thickness. In addition, each section is filled with closed-cell polyurethane, which prevents the ingress of moisture in the unlikely event of damage.
A galvanised steel or 316-grade stainless steel mooring pole runs through the centre of the assembly, to which the tower section is fastened. Four large lifting eyes aid in buoy mooring and periodic servicing.
The enhanced poly-tower design provides a huge visual area for navaid recognition, and consists of two sealed, rotationally-moulded tower sections. The lower section incorporates a battery access door and houses batteries, controllers and any ancillary electronic payload. The top section incorporates an internal radar reflector and solar mount facility.
Rotationally-moulded panelling is fitted to the outside of the tower section to create a large coloured visual area for marking. The replaceable panelling also simplifies cardinal marking and gives operators flexibility in stocking spare components. No part of the structure requires painting at any stage of the product’s life span.
An integrated ladder with harness attachment points runs vertically up the tower to the top of the platform.
High visibility red, green, white or yellow as per IALA recommendations
Robust construction of 4 quadrant hull sections
Large battery & payload section
Excellent buoyancy & stability Easy to deploy & service
Cost effective & environmentally friendly
Convenient forklift access points to safely manoeuvre the buoy assembly
Red, Green, White, Yellow as per IALA Recommendations
Focal Plane Height (mm/inches)
4500 / 177.2
Total Float Volume (Ltrs/ US gallon)
11000 / 2906
Nominal Freeboard (mm/inches)
1240 / 483/4
Nominal Freeboard (mm/inches)
1945 / 761/2
Total Researve Buoyancy (kgs/lbs)
8750 / 19290
Operational Buoyancy (kgs/lbs)
3170 / 6990
Maximum Mooring Load (kgs/lbs)
2750 / 6063
2400 / 941/2
Freeboard, Minimum (mm/inches)
800 / 311/2
Safe Working Load, 1pt (kgs/lbs)
6000 / 13228 (one lifting point)
Safe Working Load, 2pt (kgs/lbs)
8630 / 19025 (two lifting points)
Submergence (kg/cm, lb/inches)
72 / 403
7.1 / 76.4 (with daymark)
6.4 / 68.9 (without）
Water Area (m2/ft2)
2.1 / 22.6
UV-stabilised virgin polyethylene float section, tower assembly, top marks and panelling. 316-grade stainless steel fixtures.
18 / 3/4
765 / 1687 external steel
Closed-cell polyurethane foam (float section)
7900 / 311
3000 / 1181/8
2580 / 5688 (depending on payload)
Product Life Expectancy
Surface colours compliant to IALA E-108
JERRYBORG® is a registered trademark of Jerryborg Ltd
• Custom signage
• Day Mark
• Monitoring Systems (AIS, GSM)
• Unfilled Float Section
• Tower Extension-Focal Plane height:5100mm/ 2003/4 inches.
• Galvanised or stainless steel mooring post
• Flat bottom mooring post or dual mooring eyes
